Features:
- 4MP (2560 x 1440) full real-time encoding
- Max. Resolution: 2560 x 1440
- H.264, H.265, and MJPEG encoding
- Supports 4MP AHD / CVBS Video access, 2MP TVI /AHD / CVBS Video access
- Up to 128GB microSD
- Smart Analysis: Line Crossing, Intrusion, Exception Detection (Optional)
- PoE / DC12V Power Supply
- Supports Triple Streams
- CoC Control
- Supports ROI encoding
- TVS 6000V lightning protection, surge protection
The Avycon AVA-E401A-HD is an HD-TVI/AHD/CVBS Video Server, with a maximum Input resolution of 4MP (2560 x 1440). The AVA-E401A-HD supports Smart Video Analytics features, including line crossing, intrusion, and exception detection. Also included is a microSD slot with support for up to 128GB, which allows for Edge / local Recording. This Video server includes both Audio and Alarm Inputs and can be powered by either 12VDC or PoE (802.3af).
Technology
Dimensions:
Technical Details
| Video and Audio Input | |
| HD Analog Video-Input | 1 CH, BNC Interface (level: 1.0Vp-p, impedance: 75Ω) NTSC/PAL self-adaptive, 4MP AHD/CVBS Video access; 2MP TVI/AHD/CVBS Video access |
| Audio Input | 1 CH: 3.5 mm Interface, share with MIC IN Interface |
| Video | |
| Video Compression | H.265, H.264, MJPEG |
| H.264 Compression Standard | Baseline Profile / Main Profile / High Profile |
| Bit Rate Type | VBR / CBR |
| Quality | Five levels under VBR; Freely adjustable under CBR |
| Bit Rate | 32Kbps ~ 16Mbps |
| Resolution | 2560 x 1440, 2304 x 1296, 2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720, D1, CIF, 480 x 240 |
| Multi-Streams | 4MP, 3MP, 1920 x 1080, 960P, 720P, D1, CIF, 480 x 240 at Up to 30 fps |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR, etc. adjustable through client software or web browser |
| ROI | Supported |
| Audio | |
| Audio Compression | G711A/U |
| Interfaces | |
| Network | RJ45 |
| Audio | MIC IN x 1, SPK OUT x 1 |
| Storage Card | Up to 128GB |
| RS485 | Supported |
| Alarm Input | 1 CH Alarm Input |
| Alarm Output | 1 CH Alarm output |
| Local Output | 1 CH BNC output |
| Functions | |
| Remote Monitoring | IE browsing, CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 6 users; Support multi-Stream Real-Time transmission |
| Network Protocol | TCP / IP UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP |
| Interface Protocol | ONVIF, GB-T / 28181-2011 |
| Image Snap | JPEG encoding, Image quality adjustable |
| Smart Analysis | Exception detection, intrusion detection, line crossing detection |
| Ingress Protection | TVS6000V lighting protection, surge protection |
| General | |
| Power Supply | PoE/DC12V |
| Power Output | Max 12V at 0.5A |
| Power Consumption | ≤4W |
| Operating Environment | -20C ~ 55C, 10%~90% (relative humidity) |
| Dimensions | (5.51″ x 2.93 x 1.14″) 140 mm x 74.3 mm x 29 mm |
| Weight | 0.49lb |
| Installation | Wall mounting |
