Features:
- 0 Lux Minimum Illumination
- IR Light MTBF Reaching up to 30, 000 Hours
- 1/3″ High-Performance Cmos, up to 1920X1080 Resolution
- ± 0.1° Preset Accuracy
- Self-Adaptive to Pelco-P/D Protocol
- 3D Intelligent Positioning Function
- Power-Off Memory Function: Restore PTZ and Lens Status After Reboot
- Built-In Temperature Sensor, with Display of Internal Temperature
- Lightning Protection, Surge Protection and Voltage Transient Protection
- IP66 Standard (Outdoor Dome)
- Impact Protection: Iec60068-2-75 Test, EH, 20J; En50102, up to IK10
- Rs-485 Communication Diagnosis
- Scheduled PTZ Movement
- UTC (up the Coax) Function
- Auto Focus, Auto White Balance, Backlight Compensation And
- Auto/Manual Day and Night Switch
- Privacy Masks Programmable
- 3D DNR, Digital WDR
- 360° Endless Pan Range And -5° -90° Tilt Range
- 300° /S Pan Preset Speed And 200° /S Tilt Preset Speed
Dimensions:
Technical Details
| Min. Illumination | Color: 0.02 Lux at (F1.6, AGC On), B/W: 0.002 Lux at (F1.6, AGC On), 0 Lux with IR |
| HD Video Output | 1 Hd-TVI Out (up to 1200ft with Rg59u 95%) |
| White Balance | Auto / Manual / Atw / Indoor / Outdoor |
| S/N Ratio | 50dB |
| 3d Dnr | Support |
| WDR | Digital WDR |
| Shutter Time | Pal: 1-1/10, 000s, Ntsc: 1-1/10, 000s |
| Day and Night | IR Cut Filter |
| Optical Zoom | 30x |
| Digital Zoom | 16x |
| Privacy Mask | 8 Privacy Masks Programmable; a Maximum of 8 Zones Can be Masked |
| Simultaneously On The Same Video Screen | |
| Focus Model | Auto / Semiautomatic / Manual |
| Focal Length | 4-120 mm, 30x |
| Zoom Speed | Approx.3.0s (Optical Wide-Tele) |
| Angle Of View | 58-21.7 Degree (Wide-Tele) |
| Min. Working Distance | 10-1500 mm (Wide-Tele) |
| Aperture | F1.6-F4.4 |
| Pan Range | 360° Endless |
| Pan Speed | Pan Manual Speed: 0.1°-160°/S, Pan Preset Speed: 240°/S |
| Tilt Range | -15°-90° (Auto Flip) |
| Tilt Speed | Tilt Manual Speed: 0.1°-120°/S, Tilt Preset Speed: 200°/S |
| Rs-485 Communication Diagnosis | Pelco-P, Pelco-D, OSD (Utc Control) Via DVR |
| Proportional Zoom | Rotation Speed Can be Adjusted Automatically According to Zoom Multiples |
| Number Of Preset | 256 |
| Patrol | 8 Patrols, up to 32 Presets Per Patrol |
| Pattern | 4 Patterns, with the Total Recording Time not Less than 10 Minutes |
| Power-Off Memory | Support |
| Park Action | Preset / Patrol / Pattern / Pan Scan / Tilt Scan / Frame Scan / Random Scan / Panorama Scan |
| Ptz Position Display | On / Off |
| Preset Freezing | Support |
| Scheduled Task | Preset / Patrol / Pattern / Pan Scan / Tilt Scan / Frame Scan / Random |
| Scan / Panorama Scan | |
| Monitor Output | 1 Turbo HD1080p Output, 1.0V[P-P] / 75°, Ntsc (Or Pal) Composite, BNC |
| Rs-485 Interface | Half-Duplex Mode, Self-Adaptive Hikvision, Pelco-P, Pelco-D Protocol |
| Power | 24VAC (For -A Model), Max. 30W (IR: 9W, Heater: 6W) |
| Working Temperature / Humidity | -30 °C-65°C (-22°F-149°F) 90% or Less |
| Protection Level |
|
| Mounting | Various Mounting Modes Optional |
| Dimensions | D220 x 353.4 mm (D8.66″ x 13.91″) |
| Weight | 12.13lbs |
