Features:
- 5MP (2592 x 1944) @ 20fps
- Max. Resolution: 2592 x 1944
- 4-in-one HD Analog Camera:
- HD-TVI / CVI / AHD / Analog switchable by DIP switch
- Min. Illumination:
- Color: 0.03 lux @ F2.0, AGC ON
- B/W: 0 lux with IR
- Lens: Fixed 2.8mm
- Built-In MIC
- Infrared Distance: 65.6ft (20M)
- DC12V ±10%, 500mA
- NDAA Compliant
Technical Details
| Camera | |
| Image Sensor | 1/3″ CMOS Sensor |
| Image Resolution |
|
| TV System | PAL/NTSC |
| Electronic Shutter | Auto |
| Minimum Illumination | Color: 0.03 [email protected], AGC ON; B/W: 0 lux with IR |
| Scanning System | Progressive Scan |
| Lens | |
| Focus Length | 2.8mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
| Night Vision | |
| IR Cut Filter | YES |
| Infrared LED | 42μ x 1 PCS |
| Infrared Distance | 65.6 ft (20 m) |
| IR Status | AGC auto control |
| Camera Features | |
| Starlight | N/A |
| Day/Night | YES/NO |
| OSD Menu | YES |
| WDR | DWDR |
| UTC | YES |
| Noise Reduction | DNR |
| Coaxial Audio | Built-in MIC |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| General | |
| Housing | Metal |
| Bracket | NO |
| Operation Temperature | 14°F ~ 140°F (-10°C ~ +60°C, RH 95% Max) |
| Storage Temperature | -4°F ~ 140°F (-20°C ~ +60°C, RH 95% Max) |
| IP Grade | IP67 |
| Power Source | DC12V ±10%, 500mA |
| Dimension | 3.78 x 3.53 (H) ” (96 x 89mm) |
| Weight | 0.88 lb (400g) |
