| Capacity | 9,000 LB. |
| Lifting Time | Ask Your Salesperson |
| Overall Height | 111 ½” (9′ 3 ½”) |
| Overall Width | 142″ (11′ 10″) (With Power Unit) 134 ½” (11′ 2 ½”) |
| Outside Column to Outside Column | 124 ?” (10′ 4 ?”) |
| Maximum Lift Height | 74 ½” (6′ 2 ½”) |
| Minimum Arm Height | 4″ |
| Base Plate Width | 10 ¾” |
| Inside Column | 110″ (9′ 2″) |
| Drive Thru | 101″ (8′ 5″) |
| Column Size | 7 ¼” x 11 ?” |
| Column Thickness of Steel | 5mm |
| Carriage Thickness of Steel | 6mm |
| Arms Thickness of Steel | 6mm |
| Cable Diameter | .375″ |
| Base Of Lift | 13 ½” x 18 ¼” |
| Motor/Electrical Requirement | 3 HP 220V +/- 5% (209-231volts) single (1) phase. A 30 amp breaker is required. |
| Oil Requirement | 3-5 Gallons AW32/AW46 |
| Shipping Weight | 1,400 LB. |
Requires a minimum of 4″ of concrete with 3000 psi.
All lifts come with a step by step instruction manual.
