Features:
- Ultra compact powder-coated aluminum case
- Audio feedBack
- Simple automated remote control interface
- Micro-USB powered
- Free PC control application
- Micro-USB powered and controlled
- Front control buttons and OLED display
- Premium gold 26GHz SMA ports
- High reliability
The PS18000 Ku-Band Phase Shifter from DS Instruments provides handheld stand-alone and remote-controlled phase shifting from 0 to 355 degrees in 5.6-degree increments. This compact USB device features a graphic display and audio feedBack. Simple to use and integrate into automated test environments, the PS18000 is extremely attractive for many satellite-link test applications.
Typical RF Applications:
- Antenna systems
- Phased array research and development
- Beam forming projects
- Electronic warfare and defense
- Satcom systems
Phase Shift Control Application:
Technical Information / Datasheet:
Technical Details
| Frequency Range | 8000 – 18000 MHz |
| Angle Range | 0 – 355 degrees |
| Power Input Range | <+29dBm |
| Phase Resolution | 5.625 degrees |
| Insertion Loss | 10dB typical |
| Return Loss | 9dB typical |
| Input P1dB | 25dBm |
| Input IP3 | 40dBm |
| Bi-directional design | Yes |
