Flow Control Silencer Straight 1/2 inch (12.7 mm) Brass/PBT

This is a nickel-plated brass/PBT straight pneumatic flow control silencer for one-directional adjustable control of the air flow. It has 1/2 inch (12.7 mm) push-in fittings on both sides. It has NBR seals that make it suitable for applications within a temperature range from 0 to 60 °C (32 to 140 °F). The operating pressure range is -0.95 to 10 bar (-14 to 145 psi), making it suitable for vacuums. Use the rotatable needle to adjust the orifice size that defines the flow rate in one direction.

Pros:

• It has a push-in connection for easy installation and release for pneumatic hosing
• It can be used for vacuum applications

Specifications

Connection type : Push-in
Push-in connection : 1/2 inch (12.7 mm)
Material : Brass/PBT
Seal material : NBR (nitrile rubber)
Max pressure difference at 20 °C (bar) : 10
Recommended for : Vacuum
Max temperature (°C) : 60
Vacuum (bar) : -0.95
Shape : Straight
Surface protection : Nickel-plated
