Flow Control Silencer Straight 6 mm Brass/PA 66

This is a nickel-plated brass/PA 66 straight pneumatic flow control silencer for one-directional adjustable control of the air flow. It has 6 mm push-in fittings on both sides. It has NBR seals that make it suitable for applications within a temperature range from -20 to 80 °C (-4 to 176 °F). The operating pressure range is -0.95 to 20 bar (-14 to 290 psi), making it suitable for vacuums. Use the rotatable needle to adjust the orifice size that defines the flow rate in one direction.

Pros:

• It has a push-in connection for easy installation and release for pneumatic hosing
• It can be used for vacuum applications

Specifications

Connection type : Push-in
Push-in connection : 6 mm
Material : Brass/PA 66
Seal material : NBR (nitrile rubber)
Max pressure difference at 20 °C (bar) : 20
Recommended for : Vacuum
Min temperature (°C) : -20
Max temperature (°C) : 80
Vacuum (bar) : -0.95
Shape : Straight
Surface protection : Nickel-plated
