Features:
- Revolutionary stem-bush design fortrouble-free stem clamping (longerclamping range).
- No through screw holeon the frame for highdust-resistance.
- Involute curved lifting lever for smoothmovement of spindle and dovetail joint fortool-less connection
- Grater rigidity in the bearing plate forreducing the retracing error (20%) and4-screw mounting for increasing impactresistance.
Technical Details
| Digital/Analog: | Analog |
| Inch-Metric: | Inch |
| Range: | 0,1″ |
| Range per rev.: | 0,1″ |
| Graduation: | 0,0005″ |
| Accuracy: | ±0,0005″ |
| Type: | ANSI/AGD Standard |
| Stem: | 9.52 mm / 0.375″ |
| Contact point: | Carbide tipped, thread: 4-48UNF |
| Functions: | ANSI/AGD type |
