Mitutoyo, 2914AB, Series 2 Dial Gauge, Flat Back, Reverse Dial Face, 0,5″, 0.001″
Features:
- A revolutionary offset spindle bushing design provides trouble-free stem clamping and a longer clamping range
- Unique shock-proof mechanism protects against shock from sudden spindle retraction
- Rack gear is machine ground for tighter fit, increased accuracy
- Greater rigidity in the bearing plate reduces retracing error by up to 20%
- 4-Screw mounting increases impact resistance for better, longer accuracy
- No through screw hole on the frame provides better dust resistance
- Contact point is carbide tipped for lasting accuracy, durability
- Crystal is glare-free with a scratch-resistant coating
- Manufactured to meet ANSI/AGD standards
- Supplied in a fitted plastic case
The Mitutoyo one revolution dial indicator allows the entire spindle travel, or range, with one sweep of the hand. This eliminates the possibility of reading errors from miscounting multiple hand revolutions. The one-revolution indicator is ideal for determining if a spindle range is within or outside a tolerance. The jeweled bearing provides great wear resistance and low friction movements for smooth, precise operations. The stem and spindle are constructed of hardened steel for better durability. The glare-free crystal has a scratch-resistant coating for clearer readings and better durability. A revolutionary offset spindle bushing design provides trouble-free stem clamping and a longer clamping range.
Technical Details
| Digital/Analog: | Analog |
| Inch-Metric: | Inch |
| Range: | 0,5″ “ |
| Range per rev.: |
0.1″ |
| Graduation: | 0,001″ |
| Accuracy: | +/-0,001″ |
| Measuring force: | 0,4-1,8 N |
| Error of indication one revolution: | +/-0,001″ |
| Type: | ANSI/AGD Standard |
| Stem: | 9.52 mm / 0.375″ |
| Contact point: | Carbide tipped, thread: 4-48UNF |
| Continuous dial: | Yes |
| Reverse reading: | Yes 3 |
| Mass: | 139 g |
| Functions: | ANSI/AGD type |
