Mitutoyo, 314-253-30, SERIES 314 Digital 3 Flute V-Anvil Micrometer 25-40mm
Features:
- Ratchet mechanism provides an audible cl-ick to ensure measurement is being performed with a constant force
- SPC output function allows for quick and easy data management in real time
- Functions include Origin Set, Zero/ABS Setting, Data Hold, Data Output, 2 Presets, Function Lock, and inch/mm conversion (on inch/metric models only)
- Alarm: Low Voltage, Counting Value Composition Error
- Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
- Frame has a non-slip finish for better grip in shop environments
- Supplied in fitted plastic case
The Mitutoyo Digimatic V-Anvil digital micrometer pointed spindle and V-Anvil delivers precise position for highly accurate measurements. The anvil and spindle are precision milled from hardened steel for lasting, accurate results. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements. Measurements are displayed on an easy-to-read LCD readout.
Technical Details
| Digital/Analog: | Digital |
| Inch-Metric: | Metric |
| Range: | 25 – 40 mm |
| Digital step: | 0,001 mm |
| Maximum Permissible Error J MPE: | +/-5 um |
| Remarks: | – |
| Display: | LCD, character height 7.5 mm |
| Measuring face: | Prism angle 60° |
| Mass: | 465 g |
| Measuring spindle: | With spindle lock, ø6,35 mm, spindle pitch 0,75 mm |
| Scale: | Thimble and sleeve satin chrome finish, ø18 mm |
| Measuring force: | 5 – 10 N |
| Power supply: | 1 battery SR-44 |
| Battery life: | Approx. 2,4 years |
| Setting standard: | 167-329 ø 25 mm |
| Delivered: | Including box, setting standard, key, 1 battery |
| ABS / INC (INC ZERO): | Yes |
| Auto Power OFF after 20 min. non use: | Yes |
| Function lock: | Yes |
| HOLD: | Yes |
| 2 x PRESET: | Yes |
