Mitutoyo 324-352-30 Digimatic Digital Gear Tooth Micromete, 1-2″

Mitutoyo, 324-352-30, Digimatic Digital Gear Tooth Micrometer IP65, Inch/Metric, 1-2″

324-352-30 Includes Only:

• Fitted plastic case
• Key
• Setting standard
• 1 battery

Features:

• The ratchet mechanism provides an audible cli-ck to ensure the measurement is performed with a constant force
• SPC output function allows for quick and easy data management in real time
• Functions include Zero/ABS Setting, Data Hold, Data Output, Function Lock, 2 Presets, and inch/ mm conversion (on inch/metric models only)
• Alarm: Low Voltage, Counting Value Composition Error
• Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
• The frame has a non-slip finish for better grip in shop environments

The Mitutoyo Digimatic digital gear tooth micrometer measures gear modules with precision using optional interchangeable anvil-spindle tips to measure different sizes and types of gears. The Mitutoyo gear tooth micrometer measures the over-pin diameter of gears. Precision carbide anvil and spindle ball-tipped measuring surfaces are interchangeable, with optional ball-tip faces allowing for measurement of various gear modules. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements. Readings are displayed on an easy-to-read LCD readout.
