Mitutoyo 342-353-30 Point 2-3″ Micrometer w/ 15 Degrees Tip

Mitutoyo, 342-353-30, Digital Point 2-3″ Micrometer with 15 Degrees Tip

Features:

• IP65 protection permits use in environments exposed to cutting oil, coolant, dust, etc., for use on most shop floor environments
• The Ratchet mechanism provides an audible cli-ck to ensure the measurement is being performed at a constant pre-set force
• SPC output function allows for quick and easy data management in real-time
• Functions include Origin Set, Zero/ABS Setting, Data Hold, Function Lock, and inch/mm conversion (on inch/metric models only)
• Alarm: Low Voltage, Counting Value Composition Error
• Satin chrome finish on the sleeve and laser-etched measurements on the thimble for easier reading
• The frame has a non-slip finish for better grip in shop environments
• Supplied in fitted plastic case

The Mitutoyo Digimatic pointed digital micrometer features a 15-degree pointed anvil and spline to measure small grooves on parts or workpieces along with keyways and web thicknesses on drills with superior accuracy. The pointed anvil and spindle contacts are ideal for measuring small, hard-to-reach areas that a normal or reduce-diameter spindle and anvil are unable to access. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements. Measurements are displayed on an easy-to-read LCD readout.

Technical Details
