Name: Overhead 9,000 lbs. Capacity 2 Post Lift (Discontinued) See TD-9OHSC-SS-FPD
SKU: 1000-9KOH
Availability: InStock

Overhead 9,000 lbs. Capacity 2 Post Lift (Discontinued) See TD-9OHSC-SS-FPD

Capacity	9,000 LB.
Lifting Time	Ask Your Salesperson
Overall Height	142″ (11′ 10″) or 138″ (11′ 6″)
Overall Width	141″ (11′ 9″) (With Power Unit) 134 ¼” (11′ 2 ¼”)
Outside Column To Outside Column	124 ?” (10′ 4 ?”)
Maximum Lift Height (Without Adapters)	74″ (6′ 2″)
Maximum Lift Height (With Adapters)	80 ¼” (6′ 8 ¼”)
Padded Bar Height	136″ (11′ 4″) or 132″ (11′)
Minimum Arm Height	4″
Inside Column	109 ¾” (9′ 1 ¾”)
Column Size	7 ¼” x 11 ?”
Drive Thru	92 ½” (7′ 8 ½”)
Base of Lift	13 ½” x 18″
Column Thickness of Steel	5mm
Carriage Thickness of Steel	6mm
Arms Thickness of Steel	6mm
Cable Diameter	.375″
Motor/Electrical Requirement	3 HP 220V +/- 5% (209-231volts) single (1) phase. A 30 amp breaker is required.
Oil Requirement	3-5 Gallons AW32/AW46
Shipping Weight	1,450 LB.
Requires a minimum of 4″ of concrete with 3000 psi.
