Pressure Gauge 4mm Union Straight 0-16 bar (0-232psi)

This is a union straight pressure gauge for pneumatic system pressure measurement. The scale is in bar. It has 4 mm push-in fittings on both sides. The setting pressure ranges from 0 to 16 bar (0 to 232 psi). The scale division from 0 to 0.05 and measurement accuracy class 4 (± 4%). It has NBR seals that make it suitable for applications within a temperature range from -20 to 60 °C (-4 to 140 °F).

Pros:

• Equipped with easy to connect push-in fittings

Specifications

Measuring range : 0 to 16
Scale division [bar] : 0.5 bar
Accuracy class (EN) : Brass/PA66/PPS
Connection size : 4 mm
Connection type : Push-in
Material process connection : PA 66
Pressure unit : Bar
Seal material : NBR (nitrile rubber)
Cabinet material : Plastic
Connection location : Below
Max. medium temperature (continuous) (°C) : 60
Push-in connection : 4 mm
Degree of protection (IP) : IP42
Pressure gauge attachment : Direct
