Simtech, ZBC 502 6 012-A, ZBC Series, 1-1/4″ KYNAR PVDF/FPM 432 Ball Valve ANSI F to F, Flanged
All ball valves are constructed of the materials indicated. Body supplied as one piece, Utilizing no bolts, clips, or other metals to hold valve together, to prevent any radial leak paths. The stem seal is Chevron Design utilizing PTFE Packing. Manufactured as an ANSI Short Dimension. All valves be pressure and vacuum tested in both the open and closed position by the manufacture. The handle is of a safety design, with lockout/tag out option 1/2″ thru 2″ and standard (2-1/2″ to 6″), as manufactured by SIMTECH.
Features:
- Uni-body design eliminates fugitive emissions
- Ideal for highly corrosive fluids
- Lightweight design
- PTFE chevron packing
- Full port design
- Available without internal elastomers
- Low maintenance and extended operational life
- Rugged industrial design
- Cost-effective alternative to stainless steel, exotic alloy, or PTFE lined valves
Technical Details
| Hole Size (in) | 0.630 |
| A (in) | 5.51 |
| d (in) | 1.575 |
| E (in) | 7.165 |
| H (in) | 4.843 |
| I (in) | 0.630 |
| K (in) | 3.504 |
| L (in) | 5.500 |
| Size | 1-1/4″ |
| End Connection | Flanged: ANSI |
| Seals | FPM |
| Seats | PTFE |
| Material | Kynar PVDF |
| Pressure Rating | 232 psi |
| Cv | 1156 |
| Torque: Flanging (lb/in) | 177 |
| Torque: Operating (lb/in) | 133 |
