Camozzi, QCB2A040A100, Series QC 40mm Linear Ball Bearings Cylinder with Integrated Guide, 100mm Stroke
Features:
- Magnetic sensors can be mounted on both sides
- Ball bearing guide version
- Movement and guidance in one unit
For more information, please see Data Sheet
Technical Details
| Type of Construction |
|
| Operation | Double-acting |
| Materials |
|
| Mounting | Threaded and non-threaded holes in the body |
| Operating Temperature | 0°C – 80°C (with dry air – 20°C) |
| Speed | 50 – 500 mm/s |
| Operating Pressure | 1 – 10 bar |
| Fluid | Clean air, non lubricated. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted |
