Simtech, AOV 807 4 020-4, 2″ Teflon/Kalrez Air Operated Valve, Threaded – Bottom Flow Control
The SIMTECH AOV series air valve features a compact thermoplastic valve available in six models to handle a multitude of piping system functions. This patented valve is designed so there is no metal contact with the fluid, and can be operated in any position. Air actuated at 40 to 80 PSI. Direct-acting full flow with top entry for easy main te nance and minimum water hammer. Suitable for most harsh chemicals, pollution control, wet processing stations, plating equipment, chemical processing, and water treatment applications.
Technical Details
| A (in) | 6.00 |
| B (in) | 5.50 |
| C (in) | 1.700 |
| Size | 2″ |
| End Connection | Threaded: NPT |
| Seals | Kalrez |
| Material | PTFE |
| Pressure Rating | 150 psi / PN10 |
| Actuation Type | Bottom Flow Control |
| Body Type | Machined |
| Cv | 21.7 |
