Simtech, DVS 102 2 020-NC, 2″ PVC/FPM Diaphragm Valve Actuated – Normally Closed – True Union Socket
Diaphragm valves shall be weir pattern body molded from the material indicated. Diaphragms shall be as indicated. (PTFE diaphragm shall be a two-piece assembly consisting of solid PTFE diaphragm with a reinforced EPDM backing cushion.) The visual indicator is standard, as manufactured by SIMTECH.
Features:
- Position indicator standard
- Glass-Filled PP bonnet on all models
- Stainless steel assembly bolts
- Bottom Fasteners for Anchoring / Panel Mount
- High Cv Value for better flow
- Precise Flow Control
- Ergonomic handle for easy operation
Technical Details
| B (in) | 4.69 |
| C (in) | 1.614 |
| d (in) | 2.480 |
| D1 (in) | 3.858 |
| G (in) | 1/4″ |
| h (in) | 1.575 |
| H (in) | 8.150 |
| L2 (in) | 7.244 |
| L3 (in) | 7.480 |
| L4 (in) | 10.472 |
| M (in) | M8 |
| N (in) | 7.5591 |
| W (in) | 1.772 |
| Size | 2″ |
| End Connection | IPS Socket |
| Seals | FPM |
| Material | PVC |
| Pressure Rating | 232psi |
| Actuation Type | Normally Closed |
| Diaphragm | FPM |
